Collingswood Scottish Rite Auditroium Lighting Upgrade

Oct 23, 2024

Collingswood Scottish Rite Auditroium Lighting Upgrade

Collingswood Scottish Rite Project Background

The Excelsior Scottish Rite Temple, also known as the Collingswood Scottish Rite Auditorium, is a historic venue with roots tracing back to the early 20th century. Originally a mansion owned by notable figures such as Samuel French and later owned by Edward Collings Knight Sr., the property was purchased by the Excelsior Scottish Rite in 1930. Since 2003, it has been leased by the Borough of Collingswood and managed by the Collingswood Foundation for the Arts, hosting over a million guests in its classic venue for over 20 years.

Our relationship with the Scottish Rite Auditorium dates back to 2006 when Starlite upgraded their performance lighting control system to an ETC system. This long-standing partnership, coupled with our role as a rental resource for their productions and concerts, positioned us as the ideal partner for their house lighting upgrade project.

Project Challenges

The auditorium’s existing house lighting system was outdated and inefficient:

Incandescent lighting fixtures housed in glass reflectors were energy-intensive and costly to operate.

The old fixtures generated excessive heat, particularly problematic given their proximity to the historic stained glass ceiling.

The over 30-year-old Kliegl Brothers lighting control system was severely outdated.

Wall sconces throughout the theater used inefficient incandescent bulbs.

Starlite’s Solution

Starlite’s Systems Integration Team proposed and implemented a comprehensive lighting upgrade that included:

Down Lighting (House Lighting): Installed 57 new Light Source HL-series architectural LED down lights, replacing 326 incandescent fixtures.
Wall Sconces: Upgraded 12 sconces with ETC ArcLamps, transitioning from incandescent to LED technology.
Control System: Implemented a new ETC Paradigm lighting control system, including architectural lighting controls and an emergency lighting system.

Original fixtures above stained glass

New HL-series fixtures

Execution

The execution of this project was a complex undertaking that required careful planning, expert implementation, and close collaboration to navigate the unique challenges presented by the historic venue.

The project’s scope encompassed a comprehensive overhaul of the auditorium’s house lighting system. After demolition of the previous fixtures was completed, our team installed 57 new Light Source HL series architectural LED down lights, working with utmost care around and above the historic stained glass ceiling. Simultaneously, we integrated the new ETC Paradigm control system and emergency controls, replacing the outdated Kliegl Brothers system. The upgrade also extended to the theater’s decorative lighting, where we replaced the wall sconces and lamps with energy-efficient ETC ArcLamps, transitioning from incandescent to LED technology with advanced dim-to-warm functionality. This comprehensive approach ensured a complete modernization of the venue’s lighting infrastructure while preserving its historic charm.

The project’s execution was shaped by several significant challenges:

Limited Access: The historic catwalk and confined space above the antique stained glass windows posed considerable difficulties for our team during the installation of new lighting fixtures and support structures. This required innovative approaches and specialized equipment to ensure safe and effective work.

Electrical Constraints: The venue’s older electrical infrastructure, including dated wiring and conduits, necessitated careful planning and execution for new installations. Our team partnered closely with Chammings Electric Inc. (the venue’s electrical contractor) to find solutions that respected the building’s historical integrity while meeting modern electrical standards.

Delicate Work Environment: The presence of the antique stained glass ceiling demanded extraordinary care and precision. Our team implemented specialized protective measures and worked with heightened awareness to prevent any damage to these irreplaceable historical elements.

With a project having many difficulties ahead, Starlite made the entire process extremely easy to complete. Working in a space built in 1931 that hadn’t been upgraded since was a major feat. From the initial stages of design all the way through installation, the communication and customer service were incredible. Choosing fixtures that would provide the coverage and brightness we needed while shooting through the stained-glass ceiling was a challenge. The design team knocked it out of the park with their choice of fixtures. After seeing them in our theatre for a demo, we knew this was what we needed. Coming in right at, or even a little under, budget was a huge plus thanks to our sales rep, Bob Wolfe. Your installation team was nothing but professional and helpful during this process. Most of the time, they were working, and we didn’t even realize they were still in the building. Post-installation support for minor changes to programming and any questions has been amazing. We could not be happier with the overall product we received. Starlite will be our first call for any future lighting projects!

Joe Schramm

Production Manager , Scottish Rite Auditorium

Collaboration

To address these challenges and ensure the best possible outcome, Starlite collaborated closely with Brandon Creel of Hewshott, an independent theater consultancy. This partnership was crucial in developing a precise lighting design that not only worked within the venue’s architectural constraints but also met its functional and aesthetic needs. The collaborative approach allowed us to leverage combined expertise in historic venue renovations and cutting-edge lighting technology.

Throughout the execution phase, our team maintained open communication channels with the client, consultants, and other stakeholders. Joe Schramm (Production Manager) and Paula Lara (Executive Director) helped facilitate this project’s progression. This ensured that any unforeseen issues could be quickly addressed and that the project remained aligned with the client’s vision and the venue’s historical significance.

Despite the challenges, Starlite’s Systems Integration Team successfully completed the project, delivering a state-of-the-art lighting system that respects and enhances the venue’s historic character while providing significant improvements in functionality, energy efficiency, and control.

The Results

The lighting upgrade resulted in significant improvements:

Energy Efficiency: LED fixtures dramatically reduced power consumption and heat generation.
Enhanced Control: The new ETC Paradigm system provided modern, flexible lighting control options.
Improved Aesthetics: Updated house lighting and sconces enhanced the venue’s appearance while respecting its historic character.
Cost Savings: Reduced energy consumption and longer-lasting LED technology will result in long-term cost savings.

This project showcases Starlite’s ability to navigate complex, historically sensitive environments while delivering cutting-edge lighting solutions. By successfully upgrading the Collingswood Scottish Rite Auditorium’s house lighting system, we’ve not only improved the venue’s functionality and efficiency but also contributed to the preservation of a significant historical landmark.

The challenges faced and overcome during this project have further enhanced our team’s expertise, preparing us for future complex installations in historic venues.

Looking to upgrade to LED lighting?

Reach out to our experts and start your consultation today!

Illuminating a Landmark: Philadelphia City Hall Gets A Lighting Upgrade

Sep 3, 2024

Illuminating a Landmark: Philadelphia City Hall Gets A Lighting Upgrade

When the opportunity arose to collaborate on a Philadelphia lighting upgrade for the iconic City Hall, we eagerly accepted the challenge. Known for our expertise in integrating and programming exterior lighting systems, we were excited to bring a fresh, modern perspective to one of the most recognizable landmarks in the region.

City Hall Project Background

Philadelphia City Hall is more than just the largest municipal building in the United States; it’s a living testament to the city’s rich history and architectural prowess. Constructed in 1894, this Second Empire-style building is adorned with intricate sculptures and crowned by a 27-ton statue of William Penn. The building was illuminated for decades by conventional floodlights, which, while functional, did little to highlight its ornate details and grandeur.

With the advent of color-changing LED technology and a growing interest in enhancing the city’s nightscape, it was time to upgrade. The goal was to replace the outdated floodlights with a cutting-edge lighting system that could dynamically change the building’s appearance for holidays and events while being remotely controlled and easy to maintain.

Project Challenges

This Philadelphia lighting project presented several unique challenges. The lighting fixtures needed to be installed on ten separate buildings surrounding City Hall, each with its own access protocols and logistical hurdles. Additionally, the dense urban environment of Center City Philadelphia, with its high levels of RF spectrum usage and powerful cellular arrays, posed significant risks to the reliability of the wireless DMX transmission.

Because the lighting fixtures were installed on ten separate buildings surrounding City Hall, some privately held, the project timeline required detailed coordination among multiple parties. Our project partners did an exceptional job of arranging access protocols to allow our technicians to get up to the various rooftops as needed, but using the wireless and remote capabilities of the system was vital to the project’s success. To avoid spoiling the surprise of the new lighting for most residents, the programming sessions were scheduled to start late at night and go until early in the morning.

Starlite Philadelphia Lighting Solutions

Starlite’s solution for the Philadelphia lighting upgrade centered around the City Theatrical Multiverse® Wireless DMX. This was chosen for its exceptional interference rejection and reliability in crowded RF environments. We began by establishing a network of transmitters on the roof of City Hall, carefully aligning antennas to ensure a robust connection to the receiving units on the surrounding buildings.

Throughout the installation, our team used advanced tools like the RadioScan Spectrum Analyzer to select the optimal frequency ranges and troubleshoot any issues with signal transmission. Thanks to the remote capabilities of the Multiverse system, we were able to minimize the need for physical access to the equipment. This kept the project on schedule and within budget.

Our integration process also included innovative problem-solving when unexpected challenges arose. For example, when cellular arrays interfered with signal transmission, we adapted by relocating transmitters and daisy-chaining signals across remote buildings. This flexibility allowed us to maintain a strong and uninterrupted connection, ensuring the system’s reliability.

The Results

The newly illuminated Philadelphia City Hall shows off its innovation and artistry in the heart of the city. Thousands of residents and visitors pass by this landmark daily. The dynamic lighting not only enhances its architectural beauty but also serves as a wayfinding tool.

Starlite is proud to have played a role in bringing this historic building into the modern age while preserving its legacy. Our collaboration with The Lighting Practice and other project partners has resulted in a truly transformative experience, showcasing the power of technology to elevate art and architecture to new heights.

Our team of creative, detail-oriented professionals has the technical artistry, credentials, and work ethic needed to transform your current audio, visual, and/or lighting needs—and to treat you more like a person than a project.

Check out Live Design’s Q&A with Sr. Project Manager Andrew Thompson

Partner with Starlite on your next professional lighting project.

Chat with our professional lighting experts today

The Pennington School

Jul 24, 2024

The Pennington School

Enhancing Game Day Solutions at The Pennington School

Starlite’s collaboration with The Pennington School in Pennington, NJ, exemplified the successful enhancement of game day audio solutions for their outdoor football field. Starlite’s Design Engineer Paul Dietrick and Account Executive Lenny Digangi contributed to this project’s success. The focus of the project was on upgrading the audio system as part of a campus renovation initiative.

The Challenge:

The existing audio system at the outdoor football field had deteriorated due to prolonged outdoor exposure. It also had a lack of low frequency coverage, necessitating an upgrade. Starlite worked to meet the client’s desire for optimal sound quality during various activities and events.

The Solution:

After a thorough sound system analysis using Danley Direct software, Starlite recommended the best products for the installation. The Danley OS8 loudspeakers and THmini15 subwoofers were picked for their superior output levels, polar pattern, and form factor. Custom loudspeaker mounting hardware was crafted in Starlite’s on-site fabrication shop. With these customizations we were able to maximize the existing bleacher poles. This ensured a seamless integration process and provided a turnkey audio system.

The Outcome:

By strategically mounting the Danley loudspeakers on poles to cover the bleachers and field, Starlite successfully addressed architectural and noise concerns in the surrounding area. The installation of a control system, wireless microphones, gooseneck announcer microphones, a Bluetooth media player, and an audio interface plate catered to various event needs, enhancing the overall game day experience.

Client Feedback:

The system is fantastic and we’re blown away by the sound quality and clarity of the speakers. The system is used in a variety of ways: voice announcements during emergency drills, sports commentary, music and we’ve even shown a movie out on our turf field. I don’t think we could be happier with the system, installation, and service provided by Starlite.

Ken C.

Director of Technology, The Pennington School

Key Takeaways:

1. Close collaboration with The Pennington School facilitated a smooth design and execution process.Our onsite team ensured top notch customer service and easy end user training.

2. Utilization of Danley Sound Labs’ technology offered exceptional performance given the size of the loudspeaker, durability, output levels, and an aesthetically pleasing speaker box design.

3. Starlite’s commitment to delivering tailored solutions underscored its expertise in providing customized audio solutions for diverse projects from inside to outside.

In conclusion, Starlite’s contribution to The Pennington School project exemplifies its ability to enhance game day solutions through innovative audio system upgrades, showcasing a dedication to meeting client needs and ensuring optimal sound clarity for various activities and events.

Don’t let another season pass without the sound quality your fans deserve.

Upgrade with Starlite and hear the difference

Council Rock High School Auditorium

Jul 16, 2024

Council Rock High School Auditorium

Starlite’s Integration team executed Pennsylvania’s Council Rock High School auditorium lighting installation, transforming it into a state-of-the-art performance space. This bid project was submitted and won by our Lead estimator Bob Wolfe with his 20-plus years as a lighting expert. It details the collaborative efforts of the Integration team.

Scope:

The scope of the project at Council Rock involved a series of intricate tasks

Firstly the demolition of outdated stage electrics. Then replacing them with new ETC ColorSource Raceways. The ColorSource raceway allows for a custom over stage power and data solution. Utilizing a custom solution for an application like this undoubtedly allows for a much easier transition to LED lighting fixtures.

The Challenge:

Council Rock had not made the switch yet to LED and was pouring power and money into consumables

So a transition to LED theatrical lighting would eliminate costs in more than one way. While the consumables would be greatly diminished without the need for lamps and gels. The number of theatrical fixtures was also greatly reduced. This lowered the overall cost of replacement and saves more money in energy usage.

In conjunction, the space also lacked adequate navigational lighting during performances and shows. Performance groups who utilized the space craved an updated system both over the stage and in the audience. Both production value and safety of the patrons were key to the design efforts of this project. Starlite was excited to be a part of this transformation ensuring cutting edge performance lighting and safe audience lighting before, during and after use of the auditorium.

Installation team working through the demolition of outdated stage electrics.

Our Work:

Starlite’s commitment to precision is evident from the very start of any project that we take on

All materials needed for the job were first delivered to Starlite’s warehouse to ensure correct quantities and quality of the goods.We take pride in going over each individual piece of hardware that we receive to ensure that it is in perfect condition and is programmed correctly when it arrives on site. Our time with your auditorium and performing arts spaces is precious. We want to be sure that when we arrive we are ready to install fixtures, equipment racks and all other hardware.

On-site efforts included installation of 2 new tormentor lighting positions and alternate connector strips. In addition to that a comprehensive suite of stage lighting fixtures and accessories. Our rigging experts’ skills also shined during the installation process. Reaching difficult regions of the rigging system required multiple types of lifts. Starlite coordinated the work between our team and the electrical contractors on site. Often our team coordinates with electrical contractors to install high voltage components of a system in larger projects. This specific high voltage component was a custom lighting control system from ETC. ETC’s products are manufactured with performance spaces in mind and are at the cutting edge of all things theatrical.

Our ETC and CTS-I certified technician Lucas Nguyen programmed and verified installation of all theatrical fixtures, control racks and raceways in the space. Wall sconces, floor lighting, house lighting and stage lighting were all integrated into the ETC lighting system. The control surface for this space was an ETC Ion XE expertly programmed to control every light in the space. With top of the line lighting fixtures and control, Council Rock is ready to take on any performance.

ETC Ion XE control surface

End User Training:

provided extensive systems training to ensure the Council Rock staff and end-users were proficient in operating the new equipment

Project supervisor Ben Tilley was even able to train one of the students on the new system. Being able to teach students with an interest in technical theater and shape the next generation of experts made this project especially rewarding. Our engagement does not end with the installation. With the addition of our STARcare service plan on system workmanship Starlite can offer a comprehensive care plan for your new system for years to come. This can include preventative maintenance, service calls as needed and even loaner equipment as available if a repair is not possible.

Floor lighting integrated into the ETC lighting system

The Outcome:

Overall the project not only enhanced the technical capabilities of Council Rock High School’s auditorium, but also demonstrated Starlite’s ability to handle complex systems integration with a focus on quality and customer satisfaction. We believe this project exemplifies our expertise and dedication to the audiovisual and lighting industry, making us a reliable partner for your future projects.

START PLANNING YOUR AUDITORIUM OR PERFORMING ARTS CENTER UPGRADE

Winslow Township High School Auditorium

Jan 3, 2020

Winslow Township High School Auditorium

This project was a complete auditorium renovation at Winslow Township High School. This included the replacement, and upgrade of all theatrical systems, including audio, video, lighting, and rigging.

Starlite’s Systems Integration team completed this auditorium renovation after being hired by the electrical contractor DEC Electric. Starlite then provided all the equipment and labor to complete the installation of these systems. The total cost of the theatrical portion of this project was close to $750,000.

This project required careful coordination with many allied trades over many months to ensure that construction was done efficiently and without conflict. Though there were a few delays in construction (when is there not?), the contractors were able to turn over a newly renovated, fully functional theater to the school on time. The school’s theatrical team, as well as administrators were very impressed.

The rigging system included (4) Thern clew winches that allow a user to raise or lower the on stage pipe battens containing lights. This is helpful for the theatrical team to change, move, clean, adjust, etc. fixtures without use of ladders or lifts. At the FOH location, we installed a ETC 1500 Prodigy Hoist system, which allows the same convenience of the winches, with just the push of a button to trigger the electric motor.

The A/V system was highlighted by the left and right line array speakers, as well as two subwoofers that were flown above the front of the stage. The arrays were comprised of 5 Community !V6 12″ modular speakers each. Feeding these speakers were QSC CXD power amplifiers. The audio processing was done by Q-SYS Core, also by QSC. For live performances, the use of the Allen and Heath SQ 7 mixing console was integrated.

Crestron is being used for control systems. The system is designed to function in two modes: “Easy Mode”, which gives the user control through one of the two 10″ touch panels located in the back of the room, as well as on stage. This mode would be helpful for a lecture, or quick slide-show display for more of a educational setting. The other mode is “Advanced Mode”, which is typically used to live performances and is controlled through the use of the lighting and audio consoles. This allows for a more customizable setup.

The theatrical lighting fixtures were entirely furnished by ETC, all of the Color Source family. These included 20 spots, 30 pars, and 8 cycs.

Lighting is being controlled by Interactive Technologies Cue Server 2 Pro. For live performances, the user has the ability to control the lighting through the ETC Ion xe console.

Both audio and lighting consoles are neatly house in beautiful teak bodied, stainless steel roll top desks, made by HSA.

Architect: Garrison Architects
Theatrical Consultant: Starlite
General Contractor: Dandrea Construction

EQUIPMENT

RIGGING
• Thern Clew winches
• ETC Prodigy Hoist
• Rose Brand Curtains

LIGHTING
• ETC CS Spots
• ETC CS Pars
• ETC CS Cyc
• ETC Ion XE Console
• The Light Source RL120W78-30EJR LED Recessed House Lights

AUDIO
• Allen and Heath SQ7 console
• Community IV6 1122 speakers
• QSC Q-SYS Core 110f DSP
• QSC CXD Power Amplifiers
• Crestron DMPS3-4K-350 Air Media Control Processor

Lighting

ETC CS Spots
ETC CS Pars
ETC CS Cyc
ETC Ion XE Console
The Light Source RL120W78-30EJR LED Recessed House Lights

Audio

Allen and Heath SQ7 Console
Community IV6 1122 Speakers
QSC Q-SYS Core 110f DSP
QSC CXD Power Amplifiers
Crestron DMPS3-4K-350 Air Media Control Processor

Rigging

Thern Clew Winches
ETC Prodigy Hoist
Rose Brand Curtains

#
